Steel Cage Deep Groove Ball Bearings ABEC-1 Durable Front Wheel Use
SKF 6205-2rs bearing dimension parameter specification
1. Bearing model: 6205-2rs bearing
2. Bearing series: deep groove ball bearing
3. Bore diameter of bearing: 25
4. Bearing outside diameter: 52
5. Bearing thickness: 15
6. Bearing brand: SKF bearing
7. Country of origin: Sweden
8. English name: SKF 6205 Deep Groove Ball Bearing
9. Deep Groove Ball
6205-2rs bearing use
Bearings can be used for: oil coolers, acid mist purifiers, manual pumps, resistance welding machines, pre-sewing equipment, chucks, sieving
screens, spraying machines, laminating machines, vulcanization tanks, tablet presses, regeneration crushers, Field work machinery, microwave
drying equipment, winches, catering business equipment, canned pumps, auxiliary presses for plastic machines, etc.
Deep groove ball bearing characteristics and use
1. The deep groove ball bearing is simple in structure and easy to use. It is mainly used to bear the radial load, but also can bear a certain axial load.
2. When the radial clearance of the bearing increases, it has the function of angular contact ball bearing and can bear large axial load. Compared with other bearings of the same size, the friction factor of such bearings is small and the limit speed is high.
3. The thrust ball bearing can be used to bear axial load in the case of high speed.
Features of deep groove ball bearings
1. Seal typeopen, Z, ZZ, RS, 2RS, 2RZ2. Bearing stop ring:
2. N, NR3. Accuracy grade: ABEC-1, ABEC-3, ABEC-5, ABEC- 7 4.
3. Vibration level: V1, V2, V3, V45. Noise level: Z1, Z2, Z3, Z46.
4. Internal code: C0, C2, C3, C4, C5 7.
5. Bearing material: Bearing steel (9Cr18) , Stainless steel (AISI440C, AISI304, AISI316), Ceramic
6. Retainer: Stainless steel, PTFE, Nylon
7. Deep groove ball bearing is a type of ball bearing. .
8. Deep groove ball bearings mainly bear radial loads and can also bear a certain amount of axial loads. The ball bearing has a low coefficient of friction, a high limit speed, and a wide range of sizes and forms.
Steel Cage Deep Groove Ball Bearings ABEC-1 Durable Front Wheel Use
| 633 series |
| Model | I.D | O.D | thk. |
| 635 | 5 | 19 | 6 |
| 636 | 6 | 22 | 7 |
| 637 | 7 | 26 | 9 |
| 638 | 8 | 28 | 9 |
| 639 | 9 | 30 | 10 |
| 6300 | 10 | 35 | 11 |
| 6301 | 12 | 37 | 12 |
| 6302 | 15 | 42 | 13 |
| 6303 | 17 | 47 | 14 |
| 6304 | 20 | 52 | 15 |
| 6305 | 25 | 62 | 17 |
| 6306 | 30 | 72 | 19 |
| 6307 | 35 | 80 | 21 |
| 6308 | 40 | 90 | 23 |
| 6309 | 45 | 100 | 25 |
| 6310 | 50 | 110 | 27 |
Products Show
Other Bearing
| Deep groove ball bearings | Pillow block bearings | Clutch release bearings |
| Linear ball bearings | Needle roller bearings | Ball joint bearings |
| Clutch bearings | Thrust ball bearings | Thrust roller bearings |
| Conveyor roller bearings | Spherical roller bearings | Cylindrical roller bearings |
Packaging Shipping
Application
If you need, welcome contact us for price list.
